Polymer Press
Polymer Press
The Polymer Film Making equipment Polymer Press 20 Ton max pressure Films or sheets from Polymers like LDPE, HDPE, PP, POLYSTYRENE etc.
Polymer Press
Product Details:
| Minimum Order Quantity | 1 Piece |
|---|---|
| Model Name/Number | ATPHP-20 |
| Automation Grade | Automatic |
| Material | Mild Steel |
| Max Force Or Load | 0-30 ton |
| Day Light Gap | 200mm x 200mm |
| Control Type | CNC |
| Color | Athena Grey |
| Arbor Size | 140mm |
| Base Size | 200mm x 200mm |
| Cnc Or Not | Yes |
| Overall Height | 100 kgs |
| Place Of Origin | India |
| Power Source | 220V AC 50 Hzs |
Polymer Press
25T Automatic Small Hydraulic Lamination Hot Platen Press for
polymers
The Polymer Film Making equipment is ntended for preparation of cast
Films or sheets from Polymers like LDPE, HDPE, PP,
POLYSTYRENE etc.
250??? - 25T Hydraulic Lamination Hot Press with Dual Temp.
Controller/Laboratory hydraulic press
Introduction of laboratory hydraulic press
ATPHP-20
consists of a hydraulic press with manually operated oil pump & two
heated platens. The temperatures of heated platens
are controlled by two digital temperature controllers separately up
to 250°C. Water cooling jackets are installed with
heating plate that allow heated plate get faster cooling. One
pressure gauge (250 KN) is also mounted to monitor the
pressure applied on the platens. It is an excellent tool to prepare
polymer and ceramic samples.
Technical parameter of laboratory hydraulic press:
|
Max. Working Pressure |
25 metric Tone ( 250 KN) |
|---|---|
|
Pressure Gauge |
Measuring Accuracy is +/-1.25 KN |
|
Heated Platen Area
|
Platen Area: 200mm x 200mm Material: Casting Aluminum with 5 mm thick Harden Steel with Cr plated Surface:Flatting with CNC grinding |
|
Max. Travel Distance |
140mm Max. |
|
Max. Working Temperature |
200C continuous 250C for less 30 minutes |
|
Heating Rate |
3°C/min |
|
Water Cooling Jacket |
Two water cooling jacket are built on back of top and bottom heating plate separately with 1/4" water pipe connectors Such a configuration allows you cool the sample as soon as the hot pressing process is completed. |
|
Temperature Control |
Two digital controller installed in one box with one point control and auto-tune function Temperature accuracy ±1°C. |
|
Power Requirement |
110VAC or 220VAC ( 208 - 240V) |
Additional Information:
- Item Code: polymerpress
- Port of Dispatch: Mumbai
- Production Capacity: 10 monthly
- Delivery Time: 3 weeks
- Packaging Details: wooden box
